Higgs® 3

Flexible Memory Configuration

Higgs 3

  • Class leading sensitivity provided with a large memory capacity (512 bits)
  • Useful in solutions that may not be permanently connected to a network/internet
  • EPC is expandable from 96 bits to as much as 480 bits

Features Benefits

FEATURE BENEFIT DESCRIPTION
Class Leading Sensitivity Industry leading tags performance in challenging RF environments. Saves money: Reduces the number of read points and/or minimizes tag size.
800-Bits of NVRAM Larger memory RFID IC including 96-480 bits of EPC or up to 512-bits of user memory. Provides flexibility for local storage or for large bit-count EPC needs.
Dynamic Authentication™ Enhanced IC security using a non-digital, unique and non-cloneable “finger-print”. Practically eliminates copied tags being applied to counterfeit or goods of higher value.

These products are covered by one or more of the following U.S. patents: 7967204, 7931063, 7868766, 7737825, 7716208, 7716160, 7688206, 7671720, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7551141, 7542301, 7542008, 7522055, 7500610, 7489248, 7453705, 7452748, 7425467, 7417306, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157, 6942155, 6933848. Other patents pending.

Highlights

  • Highly Integrated and Cost Effective
  • Large User Memory
  • EPCglobal Gen2 and ISO/IEC 18000-6c
  • 800 Bits of Memory
  • 96-EPC Bits extensible to 480 Bits
  • 512 User Bits
  • 64 Bit Unique TID (unalterable serial number)
  • 32 Bit Access and 32 bit kill passwords
  • User Memory can be Block Perma-Locked as well as read password protected in 64 Bit Blocks
  • Low power operation for both read and programming
  • Exceptional operating range, up to 10m
