Alien GT-W Inlay

ALN-9828-W

ALN-9828-W Garment Tag “GT-W” – Higgs®-EC

Built for superior performance in high-volume Retail, the Alien Technology® ALN-9828-W GT-W is an Auburn™ certified 30×50 inlay ready for your business.

Features Benefits

FEATURE DESCRIPTION BENEFIT
30mm x 50mm form-factor tuned for dense packed retail shelves or hanging garments Designed to fit everyday densely packed retail item use cases on shelving and hangars Reliable read rates in real-life, every day retail environments
Auburn™ retail category Compliance Meets Auburn W1, W2, W3, W5, A, B, C, D, G, M, N, Q Retail categories Ensures consistent performance for all retail-type use-cases
Reliable read / write performance with Sentinel™ memory Bit error correction, improved read/write sen- sitivity, robust memory retention and 200,000 write cycles (2X that of competition) Robust reliability of stored data & added protection against data loss/corruption

These products are covered by one or more of the following U.S. patents: 7967204, 7931063, 7868766, 7737825, 7716208, 7716160, 7688206, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7551141, 7542301, 7542008, 7531218, 7522055, 7500610, 7489248, 7453705, 7425467, 7417306, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7260882, 7253735, 7244326, 7218527, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157, 6942155, 6933848, 6927085, 6816380, 6780696, 6731353, 6693384, 6683663, 6665044, 6657289, 6623579, 6606247, 6606079, 6590346, 6586338, 6566744, 6555408, 6527964, 6479395, 6468638, 6420266, 6316278, 6291896, 6281038. Other patents pending.

Applications

  • Retail/Apparel
  • Labels
  • Hang-tags
  • Joker-tags

Size

Dry Inlay

  • 1.97” x 1.18”
  • 50mm x 30mm

Wet Inlay

  • 2.09″ x 1.3″
  • 53mm x 33mm

Download

ALN-9x28-W Downloads
FileAction
ALN 9828 W (GT W) Datasheet (2019 10 30)Download
