Alien “SIT” Inlay

ALN-9613 / ALN-9713

Alien SIT Tag

The “SIT” is especially well-suited for very small item-level applications where geometries are critical. The near-field coupling properties make this tag ideal where read range requirements are short or for applications on aqueous materials.

Features Benefits

FEATURE BENEFIT DESCRIPTION
Ultra-compact without quality compromise Fits very small objects normally challenging for RFID (9mm x 12mm antenna) Application on very small items
Near-field operation only Enables a very controlled, close proximity read zone Added security
Can be used adjacent to
metallic objects
Extended read-range enabled through appropriate placement adjacent to conductive surfaces. Greater performance near challenging materials

These products are covered by one or more of the following U.S. patents: 7967204, 7931063, 7868766, 7737825, 7716208, 7716160, 7688206, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7551141, 7542301, 7542008, 7531218, 7522055, 7500610, 7489248, 7453705, 7425467, 7417306, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7260882, 7253735, 7244326, 7218527, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157, 6942155, 6933848, 6927085, 6816380, 6780696, 6731353, 6693384, 6683663, 6665044, 6657289, 6623579, 6606247, 6606079, 6590346, 6586338, 6566744, 6555408, 6527964, 6479395, 6468638, 6420266, 6316278, 6291896, 6281038. Other patents pending.

Applications

  • Jewelry Tags
  • Pharmaceutical vials
  • Bottles
  • Syringes
  • Blister packs
  • Liquids
  • Food product packaging
  • Software/video DVD’s
  • ISO Access Control or loyalty cards
  • Fashion Apparel
  • Numerous counterfeiting applications where the tag can be easily concealed

Size

Dry Inlay

  • 0.472” x 0.354”
  • 12.0mm x 9.0mm

Wet Inlay

  • 0.75” x 0.5”
  • 19.0mm x 12.7mm
