Alien Squiglette Inlay

ALN-9630 / 9730 / 9730-E / ALN-9830 / ALN-9930

The Alien Technology® “Squiglette” is a narrower version of its high-performance, general-purpose Squiggle® sibling.

ALN-9630 “Squiglette” Higgs®-3

For Squiglette applications that demand more on-tag storage of up to 800 NVAM bits. This enables storage of data for the purpose of avoiding additional network access that would otherwise be required for data retrieval.

ALN-9730/ALN-9730-E “Squiglette” & “Squiglette-E” Higgs®-4

For Squiglette applications that demand the most optimized solution for high-volume applications or other Higgs 4 advantages. Higgs 4 Squiggle offers BlastWrite™ mass-encoding for programming multiple tags at the same time, QuickWrite™ for writing a complete memory bank in one command and ultimate write-sensitivity which together provide the fastest mass-market tag encoding solution. Higgs 4 is provided pre-programmed with the ultimate enterprise-wide serialization scheme which enables efficient distributed mass-encoding of tags.

All Squiglette inlays, including ALN-9730-E are World Tag compliant, enabling operation across the diverse frequencies of the Americas, Europe, Middle East, Asia, and Africa. However, ALN-9730-E is also designed for the most challenging applications within European frequencies.

ALN-9830 “Squiglette” Higgs®-EC

Squiglette inlays are now enhanced with the reliability, robustness and readability of the new Higgs-EC IC along with all the capabilities and features of the Higgs-4 version. The Sentinel Memory within the Higgs-EC is a unique error-correcting architecture that fixes single bit errors and detects rare dual bit issues. The Higgs-EC supports over 200,000 write cycle capability, two times that of other devices on the market today. Lastly, Squiglette tags with Higgs-EC have best-in-class read and write larger sensitivity that allows larger read & write distances to be achieved and more rapid reading and encoding.

ALN-9930 “Squiglette” Higgs®-9

Merging world class design performance of the Squiggle® inlay family in a more narrow package, The Alien Technology ALN-9930 “Squiglette” offers superb range and sensitivity, suitable for a variety of smaller form factor applications.

Features Benefits

FEATURE BENEFIT DESCRIPTION
Squiggle tag performance in a smaller tag Approaches the well regarded Squiggle performance tag in a smaller form-factor Smaller form-factor, still
robust, proven, and reliable
Higgs 3 or Higgs 4 variants Large memory version (Higgs3) or optimized memory version (Higgs4). Get what you need for your application – select larger memory or mass-market optimization options.
Higgs® 4 read/write performance in the highly-efficient “Squiglette” Squiggle family tag One of Alien’s best performing general purpose tags boosted by Higgs® 4 performance and features. Highly efficient, smaller form-factor tag, still robust, proven, and reliable.
Optimized 448 bit memory footprint option Optimized for both high-performance and high-volume applications Designed to drive down the cost-of-ownership while increasing efficiencies of RFID solutions in large enterprises

These products are covered by one or more of the following U.S. patents: 7967204, 7931063, 7868766, 7737825, 7716208, 7716160, 7688206, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7551141, 7542301, 7542008, 7531218, 7522055, 7500610, 7489248, 7453705, 7425467, 7417306, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7260882, 7253735, 7244326, 7218527, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157, 6942155, 6933848, 6927085, 6816380, 6780696, 6731353, 6693384, 6683663, 6665044, 6657289, 6623579, 6606247, 6606079, 6590346, 6586338, 6566744, 6555408, 6527964, 6479395, 6468638, 6420266, 6316278, 6291896, 6281038. Other patents pending.

Applications

  • Apparel hang tags and other volume retail
  • Enterprise Wide Asset Management
  • Warehouse Management
  • Tracking Challenging Materials and Objects
  • Shipping labels
  • File folder labels
  • Pallet cards / Corrugate cases

Size

  • 2.756” x 0.374”
  • 70mm x 9.5mm

Download

ALN-9x30 Documents
FileAction
ALN 9930 Squiglette Higgs 9 (2020 07 08)Download
ALN 9830 Squiglette Higgs EC Datasheet (2018 05 15)Download
ALN 9730 E Squiglette (ST) Datasheet (2015 12 16)Download
ALN 9730 Squiglette (ST) Datasheet (2015 12 16)Download
Arkansas Radio Compliance CertificationDownload
ALN 9630 Squiglette (ST) Datasheet (2015 12 16)Download
