Alien Aviator Inlay

ALN-9850

AV

ALN-9850 Aviator™ by Alien Technology® is an Auburn™ Category U inlay providing non-stop performance from take-off to touch-down.

Features Benefits

FEATURE DESCRIPTION BENEFIT
High-performance orientation- agnostic tag applicable for a wide range of materials and world-wide frequencies. Provides performance characteristics and angular sensitivity pattern that enables tag access edge-on through a full 360°. Low turn-on threshold and high backscatter. Can be used in applications where the tag may be completely end-on to the reader antenna i.e. the tag is laid flat and the reader is “looking” at the edge of the tag.
Auburn Category U Compliant Tested and certified by Auburn University ARC program – Category U, Aviation RFID inlays Ensures consistent & robust perfor- mance in Aviation baggage tag applica- tions worldwide
Reliable read / write performance with Sentinel™ memory Bit error correction, improved read/write sensitivity, robust memory retention and 200,000 write cycles (2X that of competi- tion) Robust reliability of stored data, added protection against data loss/corruption

These products are covered by one or more of the following U.S. patents: 7967204, 7931063, 7868766, 7737825, 7716208, 7716160, 7688206, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7551141, 7542301, 7542008, 7531218, 7522055, 7500610, 7489248, 7453705, 7425467, 7417306, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7260882, 7253735, 7244326, 7218527, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157, 6942155, 6933848, 6927085, 6816380, 6780696, 6731353, 6693384, 6683663, 6665044, 6657289, 6623579, 6606247, 6606079, 6590346, 6586338, 6566744, 6555408, 6527964, 6479395, 6468638, 6420266, 6316278, 6291896, 6281038. Other patents pending.

Applications

  • Airline Baggage Tracking
  • Aviation Supply Chain
  • Inventory & Logistics
  • Wide variety of materials

Size

Dry Inlay

  • 1.496”” x 2.992”
  • 38mm x 76mm

Wet Inlay

  • 1.614” x 3.125″
  • 41mm x 79.4mm

Download

ALN-9x50 Downloads
FileAction
ALN 9850 Aviator Datasheet (2020 01 21)Download
