Readers

Our readers are built for the challenging environments that are representative in the real world. They are robust, tough and high performance even in the most challenging conditions. Our readers are different. They have advanced “filtering” and “intelligence” that competitors do not possess. This benefits you with less network traffic, fewer additional pieces of network equipment and lower setup and maintenance costs.

Product Matrix:


ALR-F800-X

ALR-F800

ALR-9900+
Commercial 4-Port RFID Reader
ALR-9680

ALR-9650
Type Enterprise with multiple reader management Enterprise Enterprise Commercial Commercial
Self Optimizing Yes Yes No No No
PoE Transmit Power World’s Highest World’s Highest N/A Good Good
Protocol ARP/LLRP ARP/LLRP ARP/LLRP ARP ARP
Operating System Linux Linux Linux Linux Linux
Emissary* Yes No No No No
Memory 1GB RAM
2 GB Flash
512 MB RAM
2 GB Flash
64 MB RAM
64 MB Flash
64 MB RAM
64 MB Flash
64 MB RAM
64 MB Flash
# of Antenna Up to 4 Up to 4 Up to 4 Up to 4 1 internal smart-antenna + 1 optional external
GPIOS 4 in / 8 out (Isolated) 4 in / 8 out (Isolated) 4 in / 8 out (Isolated) 2 in / 2 out (TTL) 2 in / 2 out (TTL)
LLRP Yes Yes Yes No No
H450
ALR-H450
S350
ALR-S350
Type Handheld – WiFi b/g/n 2.4GHz, Bluetooth, Wireless, GPS Sled Handheld – Bluetooth Low Energy connected to Smart Device
Operating System Android 4.4 (Kit Kat) Supports Apple® iOS or the latest Android® operating systems
CPU/Mem Quad-Core 1.3GHz
1 GB RAM
4 GB Flash
Embedded in selected Smart Device, Supports phones and tablets
Antenna 4dBic 5dBic with software switchable linear, circular or in proximity modes
Scanner 1-D and 2-D Barcode 1-D and 2-D Barcode

* Emissary is Alien’s multi reader configuration, management, and work-flow description solution

These products are covered by one or more of the following U.S. patents: 7716208, 7716160, 7688206, 7671720, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7215249, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157. Other patents pending.

Highlights

  • The industry’s leader in ease-of-use (setup, maintenance and daily use)
  • Best-in-class read/write performance
  • Cost savings through Aliens “intelligent” readers reducing external network infrastructure
  • Industry Leading Robustness, Intelligence & Security
