Alien GT Inlay

ALN-9728 / ALN-9828 / ALN-9828-W

ALN-9728 Garment Tag “GT” – Higgs®-4

The “GT” is a 30mm x 50mm RFID inlay form-factor especially suitable for hang-tags. This tag is specifically designed for high read performance in the retail and apparel markets where items are tightly packed on shelves or hangers.

ALN-9828 Garment Tag “GT” – Higgs®-EC

GT inlays are now enhanced with the reliability, robustness and readability of the new Higgs-EC IC along with all the capabilities and features of the Higgs-4 version. The Sentinel Memory within the Higgs-EC is a unique error-correcting architecture that fixes single bit errors and detects rare dual bit issues. The Higgs-EC supports over 200,000 write cycle capability, two times that of other devices on the market today. Lastly, GT tags with Higgs-EC have best-in-class read and write larger sensitivity that allows larger read & write distances to be achieved and more rapid reading and encoding.

Features Benefits

FEATURE DESCRIPTION BENEFIT
30mm x 50mm form-factor Designed to fit the form-factor and everyday retail use cases where items are tightly packed on shelves or hangers Extremely high read-rates in real-life, every day retail environments
Tuned for use in retail environments with packed shelves or hanging garments
Next generation Higgs™ 4 features and performance A mass-market optimized tag with class leading read and write performance. Supports Alien’s BlastWrite™ Rapid programming of serialized tags and excellent read/write performance

These products are covered by one or more of the following U.S. patents: 7967204, 7931063, 7868766, 7737825, 7716208, 7716160, 7688206, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7551141, 7542301, 7542008, 7531218, 7522055, 7500610, 7489248, 7453705, 7425467, 7417306, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7260882, 7253735, 7244326, 7218527, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157, 6942155, 6933848, 6927085, 6816380, 6780696, 6731353, 6693384, 6683663, 6665044, 6657289, 6623579, 6606247, 6606079, 6590346, 6586338, 6566744, 6555408, 6527964, 6479395, 6468638, 6420266, 6316278, 6291896, 6281038. Other patents pending.

Applications

  • Retail
  • Apparel
  • Hang-tags
  • Joker tags
  • Labels
  • Document tracking

Size

Dry Inlay

  • 1.97” x 1.18”
  • 50mm x 30mm

Wet Inlay

  • 2.125″ x 1.34″
  • 53.975mm x 33.975mm

Download

ALN-9x28 Downloads
FileAction
ALN 9828 W (GT W) Datasheet (2020 01 22)Download
ALN 9728 (GT) Datasheet (2016 07 05)Download
Arkansas Radio Compliance CertificationDownload
