ALR-9680

Low Profile, Low Overhead, 4-Port RFID Reader

Advanced Commercial 4-Port RFID Reader

Benefits

Benefit Enabled By: What does this mean to me?
Ease of Use
  • Four antenna port flexibility
  • Alien Reader Protocol
  • Smart reader/autonomous mode
  • Alien Reader Control Architecture & Ruby
  • Power-over-Ethernet (PoE)
  • Remote firmware management
  • Easy to set up and deploy
  • No additional costly controllers
  • Less maintenance and overhead
  • Minimizes network infrastructure
  • Can be set up in areas with no power
Low set-up and low-running cost
Robust yet fits narrow vertical locations
  • Robust metal chassis
  • 1¼“ tall
  • All cables on single side
Usable in:

  • Physically restricted locations
  • Locations with limited cabling

These products are covered by one or more of the following U.S. patents: 7716208, 7716160, 7688206, 7671720, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7215249, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157. Other patents pending.

Applications

  • Feature-rich Alien Reader Protocol
  • 4 mono-static reader ports
  • POE eliminates cost of AC power drop
  • EPC Gen 2 dense reader interoperable
  • Slim form-factor for installation in height-restricted places
  • Manageable and upgradeable

Documents

Not seeing a download link below? You'll Need to register or login.


ALR-9680 Documents
File
Hardware Setup Guide
ALR-9680 Datasheet (2014 12 12)
Ruby Developer's Guide
Reader Inferface Guide

Software

Not seeing a download link below? You'll Need to register or login.


ALR-9680 Software
File
Demo Software Gateway (v2.26.03)
Firmware (v140701)
Java SDK (v2.3.5)
.NET SDK (v2.3.2)
Ruby SDK

Archive

For all versions of Alien Reader Software, Gateway and SDK, visit our archive.
