Antennas

Alien provides a range of circular polarized antenna designed to meet the most challenging applications. While Alien readers are designed to work with any antenna with a suitable gain, the antenna here have been specifically designed to be paired efficiently with our readers. These antenna also work with any RFID reader. The ALR-8698 is an example of an antenna that has a narrow beam and high gain that is more unusual in the industry and can offer low power readers greater performance.

Product Matrix:

ALR-A1001 ALR-A0501 ALR-8697 ALR-8698 ALR-8696
Frequency 865-867MHz
902-928MHz
865-868MHz
902-928MHz
865 – 928MHz 866 – 928MHz 865-960MHz
Gain 8.5dBic 6dBic 8.5dBic 11 dBic (FCC)
10dBic (ETSI)
8.5dBic
Size 9.84” x 9.84” x 0.55” 5.04” x 5.04” x 0.79” 10.16” x 10.16” x 1.42” 10.2” x 10.2” x 1.32”
Cable/Connector Inset SMA male connector No cable / inset RTNC (i.e. any cable) 20ft (6m) w/RTNC
IP Rating IP67 IP54

These products are covered by one or more of the following U.S. patents: 7716208, 7716160, 7688206, 7671720, 7659822, 7619531, 7615479, 7598867, 7580378, 7576656, 7562083, 7561221, 7559486, 7559131, 7554451, 7411503, 7385284, 7377445, 7364084, 7353598, 7342490, 7324061, 7321159, 7301458, 7295114, 7288432, 7265675, 7262686, 7215249, 7214569, 7199527, 7193504, 7173528, 7172910, 7172789, 7141176, 7113250, 7101502, 7080444, 7070851, 7068224, 7046328, 6998644, 6988667, 6985361, 6980184, 6970219, 6952157. Other patents pending.

Highlights

  • Circular polarized antenna
  • All antenna work worldwide…no need to worry about regions.
  • Physically robust
  • Choice of cable lengths
  • Choice of gains and beam width
